For the first time in Korea, CPS developed new cable prodection system, "ROBO-KİT" which is used in the robotic application and prevents the cables from twisting, damaging or breaking. In addition, as Robo-kit leads the movement of cables, it minimizes the friction and interference at the same time. It makes both lifespan of cable prolonged and robot move freely.
|
|
Material | : |
High Quality Polyamide 11/12 (PAM) |
|
|
Construction | : |
Inside & Outside Corrugated Plastic tube |
|
|
Degrees of Protection | : |
IP 68 |
|
|
The max. Instantaneous Temperature | : |
-50 ºC to +95 ºC |
|
|
Short Term | : |
Up to +150 ºC |
|
|
Self-Extinguishing | : |
UL94-V2, Halogen-Free |
|
|
Color | : |
Black & Yellow |
|
|
Connections | : |
Roboway, Robo-kit, CPSFIX |
|
|
Application | : |
Robots (Welding robot, Handling robot, Rotating machinery |
| Black | Yellow | Inner Diameter (D1) | Inner Diameter (D2) | Bending Radius (R) | Packing (m/roll) |
| PAM / PAR - 22B | PAM / PAR - 22Y | 21.7 | 28.5 | 45.0 | 50 |
| PAM / PAR - 28B | PAM / PAR - 28Y | 27.8 | 34.5 | 55.0 | 50 |
| PAM / PAR - 36B | PAM / PAR - 36Y | 36.0 | 42.5 | 60.0 | 30 |
| PAM / PAR - 48B | PAM / PAR - 48Y | 46.5 | 54.5 | 70.0 | 30 |
| PAM / PAR - 56B | PAM / PAR - 56Y | 56.3 | 67.2 | 110.0 | 30 |
| PAM / PAR - 70B | PAM / PAR - 70Y | 70.0 | 82.5 | 160.0 | 10 |
| PAM / PAR - 95B | PAM / PAR - 95BY | 91.5 | 106.0 | 210.0 | 10 |
| Dİmension in mm | |||||
